| 紧凑型模块化设计
可拆卸操作面板 | 导轨安装
可插拔式I/O端子 | 穿墙安装
重载/轻载可选 |
|
|
| 物料编码 | 型号 - 无操作面板(带防尘盖)
(单相AC 200…240V, -10/+10%, 50/60Hz) | 重载
(150%, 60s) | 轻载
(120%, 60s) | 机箱 | 宽
(mm) | 高
(mm) | 深
(mm) |
| R912005395 | VFC3610-0K40-1P2-MNA-NN-NNNNN-NNNN | 0.40 kW, 2.4 A | - | B | 95 | 166 | 159 |
| R912005396 | VFC3610-0K75-1P2-MNA-NN-NNNNN-NNNN | 0.75 kW, 4.1 A | - |
| R912005397 | VFC3610-1K50-1P2-MNA-NN-NNNNN-NNNN | 1.50 kW, 7.3 A | - | C | 95 | 206 | 162 |
| R912005398 | VFC3610-2K20-1P2-MNA-NN-NNNNN-NNNN | 2.20 kW, 10.1 A | - | D | 120 | 231 | 167 |
|
|
|
|
|
|
|
|
| 物料编码 | 型号 - 无操作面板(带防尘盖)
(三相AC 380…480V, -15/+10%, 50/60Hz) | 重载
(150%, 60s) | 轻载
(120%, 60s) | 机箱 | 宽
(mm) | 高
(mm) | 深
(mm) |
| R912005399 | VFC3610-0K40-3P4-MNA-NN-NNNNN-NNNN | 0.40 kW, 1.3 A | - | B | 95 | 166 | 159 |
| R912005400 | VFC3610-0K75-3P4-MNA-NN-NNNNN-NNNN | 0.75 kW, 2.3 A | - |
| R912005401 | VFC3610-1K50-3P4-MNA-NN-NNNNN-NNNN | 1.50 kW, 4.0 A | - | C | 95 | 206 | 162 |
| R912005402 | VFC3610-2K20-3P4-MNA-NN-NNNNN-NNNN | 2.20 kW, 5.6 A | - |
| R912005403 | VFC3610-3K00-3P4-MNA-NN-NNNNN-NNNN | 3.00 kW, 7.4 A | - | D | 120 | 231 | 167 |
| R912005404 | VFC3610-4K00-3P4-MNA-NN-NNNNN-NNNN | 4.00 kW, 9.7 A | - |
| R912005405 | VFC3610-5K50-3P4-MNA-NN-NNNNN-NNNN | 5.50 kW, 12.7 A | 7.50 kW, 16.8 A | E | 130 | 243 | 225 |
| R912005406 | VFC3610-7K50-3P4-MNA-NN-NNNNN-NNNN | 7.50 kW, 16.8 A | 11.0 kW, 24.3A |
| R912005407 | VFC3610-11K0-3P4-MNA-NN-NNNNN-NNNN | 11.0 kW, 24.3 A | 15.0 kW, 32.4A | F | 150 | 283 | 225 |
| R912005408 | VFC3610-15K0-3P4-MNA-NN-NNNNN-NNNN | 15.0 kW, 32.4 A | 18.5 kW, 39.2 A |
| R912005409 | VFC3610-18K5-3P4-MNA-NN-NNNNN-NNNN | 18.5 kW, 39.2 A | 22.0 kW, 45.0 A | G | 165 | 315 | 233 |
| R912006276 | VFC3610-22K0-3P4-MNA-NN-NNNNN-NNNN | 22.0 kW, 45.0 A | 30.0 kW, 60.8 A |
|
|
|
|
| 物料编码 | 型号 - LED显示操作面板
(单相AC 200…240V, -10/+10%, 50/60Hz) | 重载
(150%, 60s) | 轻载
(120%, 60s) | 机箱 | 宽
(mm) | 高
(mm) | 深
(mm) |
| R912005373 | VFC3610-0K40-1P2-MNA-7P-NNNNN-NNNN | 0.40 kW, 2.4 A | - | B | 95 | 166 | 167 |
| R912005374 | VFC3610-0K75-1P2-MNA-7P-NNNNN-NNNN | 0.75 kW, 4.1 A | - |
| R912005375 | VFC3610-1K50-1P2-MNA-7P-NNNNN-NNNN | 1.50 kW, 7.3 A | - | C | 95 | 206 | 170 |
| R912005376 | VFC3610-2K20-1P2-MNA-7P-NNNNN-NNNN | 2.20 kW, 10.1 A | - | D | 120 | 231 | 175 |
|
|
|
|
|
|
|
|
| 物料编码 | 型号 - LED显示操作面板 (三相AC 380…480V, -15/+10%, 50/60Hz) | 重载
(150%, 60s) | 轻载
(120%, 60s) | 机箱 | 宽
(mm) | 高
(mm) | 深
(mm) |
| R912005377 | VFC3610-0K40-3P4-MNA-7P-NNNNN-NNNN | 0.40 kW, 1.3 A | - | B | 95 | 166 | 167 |
| R912005378 | VFC3610-0K75-3P4-MNA-7P-NNNNN-NNNN | 0.75 kW, 2.3 A | - |
| R912005379 | VFC3610-1K50-3P4-MNA-7P-NNNNN-NNNN | 1.50 kW, 4.0 A | - | C | 95 | 206 | 170 |
| R912005380 | VFC3610-2K20-3P4-MNA-7P-NNNNN-NNNN | 2.20 kW, 5.6 A | - |
| R912005381 | VFC3610-3K00-3P4-MNA-7P-NNNNN-NNNN | 3.00 kW, 7.4 A | - | D | 120 | 231 | 175 |
| R912005382 | VFC3610-4K00-3P4-MNA-7P-NNNNN-NNNN | 4.00 kW, 9.7 A | - |
| R912005095 | VFC3610-5K50-3P4-MNA-7P-NNNNN-NNNN | 5.50 kW, 12.7 A | 7.50 kW, 16.8 A | E | 130 | 243 | 233 |
| R912005096 | VFC3610-7K50-3P4-MNA-7P-NNNNN-NNNN | 7.50 kW, 16.8 A | 11.0 kW, 24.3A |
| R912005097 | VFC3610-11K0-3P4-MNA-7P-NNNNN-NNNN | 11.0 kW, 24.3 A | 15.0 kW, 32.4A | F | 150 | 283 | 233 |
| R912005098 | VFC3610-15K0-3P4-MNA-7P-NNNNN-NNNN | 15.0 kW, 32.4 A | 18.5 kW, 39.2 A |
| R912005383 | VFC3610-18K5-3P4-MNA-7P-NNNNN-NNNN | 18.5 kW, 39.2 A | 22.0 kW, 45.0 A | G | 165 | 315 | 241 |
| R912006277 | VFC3610-22K0-3P4-MNA-7P-NNNNN-NNNN | 22.0 kW, 45.0 A | 30.0 kW, 60.8 A |
| 注：以上所有价格均为不含税价 |
|
|
|
|
|
|
